Q-SYS™ Core Nano는 Q-SYS Core 제품군에 최근 추가된 제품으로, 기업, 학교, 의료 시설 및 그 이상의 더욱 광범위한 소규모 환경에 설치되어 시스템을 보다 최적화하여 구성을 가능하게 합니다.

64 x 64 네트워크 채널
I/O 선택하여 사용 가능한 8개의 온보드 플렉스 채널 및 GPIO
8 AEC 프로세서
8 x 8 기본 제공 단테 채널(32 x 32 업그레이드하여 사용 가능)
USB AV 브릿징 기능(8 x 8 audio + Q-SYS camera support)
손쉽고 다양하게 활용 가능한 Q-SYS Control 엔진(라이센스 필요)
외부 USB 오디오 장치 연결 가능
최대 2개의 VoIP 지원
1U 절반 너비로 컴펙트한 사이즈

System details

Audio inputs
Phantom power : +48VDC, 10mA per input max
A/D-D/A converters : 24bit
Sample rate : 48kHz

Input frequency response
20Hz to 20kHz @ +24dBu : +0.05dB / -0.5dB

Input THD+N @ 1kHz
@ +24dBu sensitivity & +24dBu input : < 0.1%
@ +24dBu sensitivity & +10dBu input : < 0.0015%
@ +10dBu sensitivity & +8dBu input : < 0.001%
@ -10dBu sensitivity & -10.5dBu input : < 0.001%
@ -39dBu sensitivity & -39.5dBu input : < 0.007%

Input to input crosstalk @ 1kHz
@ +24dBu sensitivity : 110dB typical, 90dB max
@ +10dBu sensitivity : 105dB typical, 90dB max
@ -10dBu sensitivity : 100dB typical, 90dB max
@ -39dBu sensitivity : 75dB typical

Input dynamic range
@ +24dBu sensitivity : > 109.5dB
@ +10dBu sensitivity : > 106.4dB
@ -10dBu sensitivity : > 104.6dB

Input common mode noise rejection
@ +24dBu sensitivity : < 51, 20Hz-3kHz
           < 43, 20Hz-10kHz
           < 36, 20Hz-20kHz
@ +10dBu sensitivity : < 57, 20Hz-3kHz
           < 47, 20Hz-10kHz
           < 41, 20Hz-20kHz
@ -10dBu sensitivity : < 67, 20Hz-3kHz
           < 58, 20Hz-10kHz
           < 53, 20Hz-20kHz
@ -39dBu sensitivity : < 60, 20Hz-3kHz
           < 54, 20Hz-10kHz
           < 50, 20Hz-20kHz
Input impedance(balanced) : 7.2kΩ nominal
Input sensitivity range(1dB steps) : -39dBu minimum to +24dBu maximum

Audio outputs
Output frequency response
20Hz to 20kHz @ all settings : + 0.2 / -.5dB
Output THD : 0.005% typical, +24dBu max output level
EIN(no weighting, 20Hz to 20kHz) : < -121dB
Output crosstalk @ 1kHz : > 100dB typical, 90dB max
Output dynamic range : > 108dB
Output impedance(balanced) : 332Ω

Channel capacity
Q-LAN channels : 64 x 64
Dante channels : 8 x 8(included); up to 32 x 32 with optional license
AEC channels : 8
WAN / media stream channels : 12 x 12
Network peripherals : up to 32
Audio recording / playback : 4ch recording / 16ch playback (expandable to 32ch with optional license)

Control
RS232 : 2ports
GPIO : 8 x 8

USB inputs & outputs
USB B or C(audio)
Bit depth : 16bit
Channel count : 8 x 8
Sample rate : 48kHz
USB audio device hosting : Support for standard USB headset, speakerphone on USB type A connection(one device at a time)

Input
Sample rate : 48k or 16k, mono
Resolution : 8-bit, 16-bit, 24-bit, 32-bit, float
Format : little-endian, signed or unsigned

Output
Sample rate : 48k only, stereo
Resolution : 8-bit, 16-bit, 24-bit, 32-bit, float
Format : little-endian, signed or unsigned

Physical
Device dimensions(HxWxD) : 1.72 x 8.66 x 11.28in(43.6 x 220 x 286.6mm)
Shipping dimensions(HxWxD) : 3.1 x 13.3 x 15in(79 x 337 x 381mm)

Environmental & safety
Power consumption : 40W typical
BTU/heat load : 110BTU/hour
Compliance : FCC part 68 / TIA-968-B(USA)
        ES203 021, CE, RoHS(Europe),
        PTC200(New Zealand)
        NOM-151-SCTI(Mexico)
        JATE(Japan)
        UL and C-UL listed(USA & Canada)
        AC(Eurasian Customs Union)
        PSTN01(Taiwan)
        Industry Canada CS-03(Canada)
        AS/ACIF S002 and RCM(Australia)
        ANATEL Resolution 473(Brazil)
