FEATURES
|
Rigid center gooseneck 30kHz frequency response Uniform frequency response on or off axis More gain before feedback Picks up almost no sound from the rear of the microphone Near perfect polar pattern Programmable touch sensor output Programmable dual-colored LED light ring Light ring engineered for a wide supply voltage range (From 8V to 28V regulated supply—No external LED resistors needed) Touch sensitive flange that provides a pull down touch sensor output (Active Low) Light diffuser that houses 10 LEDs providing side illumination (5 Green, 5 Red) Current consumption 85mA Supplied with either a 5 pin RJ45 connector or a 5 pin Phoenix connector Primary applications include teleconferencing, distance learning, surveillance, boardrooms, government facilities, and ambient room miking |
SPECIFICATIONS
|
Frequency response : 100Hz to 30kHz Polar pattern : Cardioid Sensitivity : 20mV/Pa(-34dBV/Pa) Power requirements : 48V Phantom, 10mA Max acoustic input : 139dB SPL Output : XLR(pin 2+) LumiComm™ connector : Phoenix or RJ45 Output impedance : 65Ω balanced (between pins 2 & 3) Min output load : 600Ω between pins 2 & 3 Current consumption : 85mA Noise : 16dB SPL equivalent(A weighted) |
